Pipe Fabrication Production Line (Transportable Type)

Model: SPFPL-16Aa/24Aa

• Production Capacity: 20-80 thousands diameter-inch/month (or depending on workshop area and equipment configuration or as per request)
• Pipe diameter applicable: DN400/DN600
• Pipe Thickness: 3-80MM
• Conveying Speed: 2-20M/Min
• Beveling Speed: ≤5Min/Two Bevels (DN200 SCH40)
• Automatic Welding Rate: ≥60%
• Prefabrication Ratio: 50%~80%
• Design Software: PDSOFT 3Dpiping
• Management Software: PDSOFT SPFMS

Applications
The pipe fabrication production line is used on piping projects all over the country where the total amount of work is on a smaller scale.

• The basic configuration of the pipe fabrication production line consists of many sets of pipe cutting and bevel machining workstation, many sets of mechanical fitting-up workstation, many sets of piping automatic welding workstation, a set of conveying system and a set of steel structure pipe racks.
• The pipe fabrication production line offers high production efficiency - hoisting with cantilever crane, beveling with pipe bevel machining workstation and welding with piping automatic welding workstation.
• It offers excellent equipment mobility without the limitation of radiation radius by using container as carrier.
• Utilized the local place on project site; Using PDSOFT Pipe Fabrication Detail Design Software for designing spool pieces; Using PDSOFT Pipe Fabrication Process Management Software to elaborate management with high efficiency; Using CNC cutting & beveling equipment for high quality mechanical beveling; Using fitting-up machine for fast spool pieces fit-up; Using Split type Pipe Fabrication Automatic Welding Machine for high-efficiency high-quality MIG root welding with QSPT’s technology; Using SAW for high efficiency cap welding; configure with adequate numbers of conveying systems capable of longitudinal/lateral conveying to ensure safe and reliable ground conveying.
