Pipe Fabrication Production Line (Numerical Control Type)

Model: NPPPL-24A

• Production Capacity: 20-150 Thousands Diameter-Inch/Month (or depending on workshop area or equipment configurations)
• Pipe Diameter: DN50-600 (φ60-610mm)
• Pipe Thickness: 3-80MM
• Conveying Speed: 2-20M/Min
• Beveling Speed: ≤5Min / Two Bevels (DN200 SCH40)
• Automatic Welding Rate: ≥60%
• Prefabrication Ratio: 50%~80%
• Design Software: PDSOFT 3Dpiping
• Management Software: PDSOFT SPFMS

Applications
This numerical control type pipe fabrication production line is used for pipe projects or piping prefabrication projects are within 500KM from the center of the workshop.

• The basic configuration of the pipe fabrication production line consists of one set of fixed-type high speed pipe cutting and beveling machine(plc), one set of roller-bench-type pipe plasma cutting and beveling machine(nc), one set of high speed pipe cutting band saw machine + two sets of fixed-type pipe end beveling machine(plc), many sets of piping prefabrication fast fitting-up machine, many sets of piping prefabrication automatic welding machine or piping cantilever automatic welding machine, many sets lateral transport system, a set of longitudinal transport system, a set of piping prefabrication marking system, a set of real time manufacturing monitoring system, a set of real time data acquisition system and a set of steel structure pipe racks.
• The pipe fabrication production line offers excellent production efficiency - hoisting with overhead traveling crane, beveling with high speed pipe cutting and beveling machine and welding with automatic welding machine.
• The equipment cannot be easily moved.
